4-20mA input to 4-20mA re-transmission output plug-on digital readout. This compact LED indicator adds a local digital display to any 4-20mA device with a DIN 43650 plug and socket.
PA430 Add-On LED Display
- Analogue Output: 4-20mA, ATEX IS, (2 wire)
- Switch Contacts: Not required
- Electrical Connection (Output from Display): DIN43650A plug IP65
- Electrical Connection (Input from Sensor): DIN43650A plug IP65
- Engineering Unit Label: Fitted by user
